26-27|03|2026
Kortrijk Xpo

NXT 06

arrow Manufacturing hub NXT06 - FANUC

Machineering NextGen Experience will feature five 'manufacturing Hubs'. Here, various partners will join forces to showcase innovations as part of 9 large-scale, live production demonstrations. This will be perfect place to show everyone how machines, tooling, automation and digitalisation can be combined to manufacture products efficiently in a future-proof environment. A standalone machine can only really be useful when it is supported by the right tooling, automation and digitalisation.

Visit Machineering NextGen Experience and discover your production live in action.

REGISTER YOUR VISIT
NXT06

NXT06 PARTNERS

fanuc

Hub NXT06B

blum novotest

BOOTH 512C

cad2m

NXT06B

bokhoven

NXT06B

helder

NXT06B

TECMOTOOLS

NXT06B

TECHMOFLUIDS

NXT06B

TECHMO MACHINERY

NXT06B

Live production floor
Production Line 1
  1. Supply
    Raw material is randomly stacked on a pallet.
  2. Detection & Localization
    Helder AI Vision scans the pallet, detects all raw blocks, and precisely determines their positions.
  3. Picking & Loading the Milling Machine
    The FANUC M-710iD/70 robot picks up a detected block and places it into the ROBODRILL, equipped with a 5-axis Lehmann table.
  4. Milling Operation
    The ROBODRILL mills the end product selected by the visitor from the raw material (3 options).
  5. Unloading the Milling Machine & Placement
    The FANUC M-710iD/70 removes the finished part from the machine and places it on the finished products pallet.
Production Line 2
  1. Localization on the Pallet
    The FANUC CRX-30iA cobot, equipped with the FANUC 3D Area Sensor, automatically detects and localizes all boxes randomly positioned on the pallet.
  2. Picking & Stacking into the Cart
    The cobot picks up the detected boxes one by one and stacks them neatly into a cart.
  3. Detection in the Cart
    Once all boxes are placed in the cart, the cobot scans again and determines the exact positions of the stacked boxes.
  4. Restacking onto a Pallet
    The cobot then removes the boxes individually from the cart and restacks them onto a pallet.
Production Line 3
  1. Recognition & Positioning
    The FANUC CRX-10iA/L Paint cobot localizes the racing bicycle helmets and automatically determines the correct paint position.
  2. Smooth Paint Spraying Process
    The FANUC CRX-10iA/L Paint cobot demonstrates smooth and highly controlled movements while spraying the helmets evenly and precisely.
  3. Final Result
    The racing bicycle helmets receive a professional, uniform, high-quality paint finish, fully executed by the FANUC CRX-10iA/L Paint cobot.

Which technologies can you expect

Y500

1. Compact CNC Machining Center - MILLING - FANUC ROBODRILL ADV Plus Y500

The ROBODRILL Y500 delivers outstanding performance in high-precision milling thanks to its extended 500 mm Y-axis stroke and enhanced Z-axis acceleration for fast, accurate material removal. Its ultra-fast 28-tool Automatic Tool Changer and large 850 × 500 mm table make it ideal for advanced 5-axis milling strategies and complex multi-sided machining.

fanuc

2. NEW! Handling Robot with 70 kg Payload - FANUC M-710iD/70

NEW! The FANUC M-710iD/70 stands out with its unique curved J2 arm and fully enclosed, dust- and water-resistant design (IP67/IP54), enabling reliable operation in confined spaces and harsh industrial environments. With a reach of 2104 mm, a 70 kg payload, and exceptional ±0.03 mm repeatability, it delivers maximum flexibility and top performance in handling, assembly, and palletizing applications.

CXR-10iA/L

3. NEW! Paint Cobot - FANUC CRX-10iA/L Paint

The FANUC CRX-10iA/L Paint is the world’s first explosion-proof, ATEX-certified collaborative paint robot, designed for extremely safe and precise painting, coating, and spraying applications. With a reach of 1418 mm and a 10 kg payload, it features a unique underflip motion for confined spaces, intuitive drag-and-drop programming, and 8 years of maintenance-free reliability, elevating automation in paint environments to a new level.

CXR-30iA

4. Cobot with up to 30 kg Payload - FANUC CRX-30iA Collaborative Robot

The FANUC CRX-30iA is a powerful collaborative robot designed for demanding handling tasks such as palletizing, machine tending, and material handling. With its 30 kg payload, 1756 mm reach, and unique underflip motion, this cobot provides exceptional flexibility for stacking high pallets and operating within compact production setups.
